New Fanless i7 Skylake PC with upcoming Akasa Euler-TX Aluminium Case

Posted

* NOW IN STOCK... SEE TX SERIES *

Coming in December is our new Fanless Quad Core i7 Skylake PC using the new Akasa Euler-TX aluminium case.  This case uses longer cooling fins and a larger body than the standard Euler Series. In our testing this produces excellent cooling, enabling the i7 6700T to be well cooled even under extreme loads.

Standard Features include:

  • 4 x USB 2.0 Ports on the Front, so both the ASUS H110T and Q170T are suitable motherboards
  • 1 x Serial Port (optional) on rear
  • 2 x Antenna Ports (optional) on rear
  • 1 x 2.5" SSD/HDD mounting on inside of case (not user accessible)
  • VESA 100x100 Mounting Kit
  • Dimensions: 262.6 x 215 x 68.5 mm (WxDxH)

Skylake i7 6700T CPU Temperatures, at 22°C room temperature:

  • Under 32°C running Windows 10 desktop
  • Under 72°C running 4 cores at 100% continually (hours), using Passmark BurninTest

Unique to Atlast! Solutions:

  • Assembled with ASUS Q170T motherboard and the latest Samsung M.2 PM961 256GB SSD
  • The SSD has over 3000MB/s read speed and 1150MB/s write speed
  • The M.2 SSD is thermally joined to the case using an internal aluminium block
  • The M.2 SSD can be used continually without throttling

Click to view full size:

Akasa Euler-TX  Akasa Euler-TX with Q170T Motherboard

This photo with the back plate removed shows the longer cooling fins, and our internal M.2 SSD cooling block:
